Chapter 3 Signal Connections

NI 660x User Manual 3-22 ni.com

Table 3-9 lists the signals and the D GND pin number on the 68-pin

connector block.

Table 3-9. Signals and D GND Pin Number on 68-Pin Connector Block

PFI Number Pin Number for D GND

PFI 0 11

PFI 1 11

PFI 2 46

PFI 3 46

PFI 4 14

PFI 5 14

PFI 6 49

PFI 7 49

PFI 8 50

PFI 9 50

PFI 10 18

PFI 11 18

PFI 12 20

PFI 13 20

PFI 14 55

PFI 15 55

PFI 16 24

PFI 17 24

PFI 18 59

PFI 19 59

PFI 20 27

PFI 21 17

PFI 22 62

PFI 23 62
