© National Instruments Corporation 1-1 R Series Multifunction RIO User Manual
1
Introduction
This chapter describes the NI 781xR/783xR/784xR/785xR, the concept of
the Reconfigurable I/O (RIO) device, optional software and equipment for
using the NI 78xxR, and safety information about the NI 78xxR.
About the Reconfigurable I/O Device
Table 1-1 lists an overview of the NI 78xxR R Series Multifunction RIO
devices.
A user-reconfigurable FPGA (Field-Programmable Gate Array) controls
the digital I/O lines on the NI 781xR, and the digital and analog I/O lines
on the NI 783xR/784xR/785xR. The FPGA on the R Series device allows
you to define the functionality and timing of the device. You can change the
functionality of the FPGA on the R Series device in LabVIEW using the
LabVIEW FPGA Module to create and download a custom virtual
Table 1-1. NI 78xxR R Series Multifunction RIO Device Overview
Device I/O Channels FPGA AI Sample Rate
NI PCI/PXI-7811R 160 DIO Virtex-II XC2V1000 —
NI PCI/PXI-7813R 160 DIO Virtex-II XC2V3000 —
NI PCI/PXI-7830R 4 AI, 4 AO, 56 DIO Virtex-II XC2V1000 200 kS/s
NI PCI/PXI-7831R 8 AI, 8 AO, 96 DIO Virtex-II XC2V1000 200 kS/s
NI PCI/PXI-7833R 8 AI, 8 AO, 96 DIO Virtex-II XC2V3000 200 kS/s
NI PCIe/PXI-7841R 8 AI, 8 AO, 96 DIO Virtex-5 LX30 200 kS/s
NI PCIe/PXI-7842R 8 AI, 8 AO, 96 DIO Virtex-5 LX50 200 kS/s
NI PCIe/PXI-7851R 8 AI, 8 AO, 96 DIO Virtex-5 LX30 750 kS/s
NI PCIe/PXI-7852R 8 AI, 8 AO, 96 DIO Virtex-5 LX50 750 kS/s
NI PXI-7853R 8 AI, 8 AO, 96 DIO Virtex-5 LX85 750 kS/s
NI PXI-7854R 8 AI, 8 AO, 96 DIO Virtex-5 LX110 750 kS/s
