© National Instruments Corporation A-1 R Series Multifunction RIO User Manual
A
Connecting I/O Signals
This appendix describes how to make input and output signal connections
to the NI 78xxR I/O connectors.
Figure A-1 shows the I/O connector pin assignments and locations for
NI PCI-7811R/7813R and NI PXI-7811R/7813R.
Figure A-2 shows the I/O connector pin assignments and locations
for NI PCI-7830R/7831R/7833R, NI PCIe-7841R/7842R/7851R/7852R,
and the NI PXI-7830R/7831R/7833R/7841R/7842R/7851R/7852R/
7853R/7854R.
Note The NI PXI-7830R and NI PCI-7830R do not have Connector 2 (RDIO).
