Chapter 2 Hardware Overview of the NI 78xxR
© National Instruments Corporation 2-25 R Series Multifunction RIO User Manual
Figure 2-15. Switch Location on the NI PCI-783xR
Figure 2-16. Switch Location on the NI PXI-783xR
SW1, SW2, SW3
SW1, SW2, SW3
CONNECTOR 2 (DIO)
NI PXI-7831R
Reconfigurable I/O
