10 | ni.com | Foundation Fieldbus Hardware and NI-FBUS Software Installation Guide
Figure 8 shows the distance between the bottom screw notch and the upper mounting tab on the
USB-8486.
Figure 8. Dimensions of the Mounting Tab and Notch
15.24 mm
(0.600 in.)
78.22 mm
(3.079 in.)
