Foundation Fieldbus Hardware and NI-FBUS Software Installation Guide | © National Instruments | 7
DIN Rail Mounting
You can use the DIN-rail mounting kit to mount your USB-8486 to a standard DIN rail, as shown
in Figure 5.
Figure 5. Fastening a DIN Rail Clip to the USB-8486
1 USB-8486 2 DIN Rail Clip 3 Thread-Forming Screws
1
3
2
