40 | ni.com | NI PXI-4130 Calibration Procedure
1 200 mA 20 V 20 V 1 2.00 mA
2 24.0 mA
3 46.0 mA
4 68.0 mA
5 90.0 mA
6 112 mA
7 134 mA
8 156 mA
9 178 mA
10 200 mA
-20 V 11 2.00 mA
12 24.0 mA
13 46.0 mA
14 68.0 mA
15 90.0 mA
16 112 mA
Table 20. NI 4130 Output Parameters and Test Limits for Current Programming
Accuracy Adjustment (Continued)
Channel
Current
Limit
Range
Voltag e
Level
Range
Voltag e
Level
Iteration Output
