Chapter 1 Introduction
R Series Multifunction RIO User Manual 1-8 ni.com
Cables and Accessories
National Instruments offers a variety of products you can use with R Series
devices, including cables, connector blocks, and other accessories,
as shown in Table 1-3.
Refer to Appendix A,
Connecting I/O Signals, for more information
about using these cables and accessories to connect I/O signals to the
NI 78xxR. Refer to
ni.com/products or contact the sales office nearest
to you for the most current cabling options.
Table 1-3. R Series Connectivity Options
Cable
Connector
Accessory DescriptionNI 781xR
NI 783xR/
784xR/785xR
SHC68-68-RMIO
(NI Recommended)
— 0 NI SCB-68 High-performance shielded cable
wired specifically for signal
connection from the RMIO
connector
*
to the NI SCB-68
terminal block to provide higher
signal integrity and noise immunity.
SHC68-68-RDIO
(NI Recommended)
0, 1, 2, 3 1, 2
†
NI SCB-68 High-performance shielded cable
wired specifically for signal
connection from the
RDIO connector
*
to the NI SCB-68
terminal block to provide higher
signal integrity and noise immunity.
SH68-C68-S 0, 1, 2, 3 1, 2
†
NI SCB-68 Basic shielded cable for signal
connection from the RMIO or
RDIO connector to the NI SCB-68
terminal block for noise reduction.
*
For a diagram of the twisted pairs in the SHC68-68-RMIO and SHC68-68-RDIO cables and the signals to which they
correspond, go to
ni.com/info and enter the info code rdrmio.
†
NI 7830R does not have Connector 2.
