Chapter 1 Introduction
© National Instruments Corporation 1-9 R Series Multifunction RIO User Manual
Custom Cabling
NI offers a variety of cables for connecting signals to the NI 78xxR. If you
need to develop a custom cable, a nonterminated shielded cable is available
from NI. The SHC68-NT-S connects to the NI 78xxR VHDCI connectors
on one end of the cable. The other end of the cable is not terminated. This
cable ships with a wire list identifying the wires that correspond to each
NI 78xxR pin. You can use this cable to quickly connect the NI 78xxR
signals that you need to the connector of your choice. Refer to Appendix A,
Connecting I/O Signals, for the NI 78xxR connector pinouts.
