Chapter 2 Hardware Overview of the NI 78xxR
R Series Multifunction RIO User Manual 2-24 ni.com
Figure 2-13. Switch Location on the NI PCI-781xR
Figure 2-14. Switch Location on the NI PXI-781xR
SW1, SW2, SW3
NI PXI-
7811R
Reconfigurable I/O
CONNECTOR 2 (DIO)CONNECTOR 3 (DIO)
SW1, SW2, SW3
