Optional Items
• PXI slot blocker kit (NI part number 199198-01)
• SCB-19 connector block (NI part number 785642-01)
• SHH19-MH19-AUX shielded single-ended cable, 1 M (NI part number 784091-01)
Visit ni.com for more information about these additional items.
Preparing the Environment
Ensure that the environment you are using the PXIe-5413 in meets the following
specifications:
Maximum altitude 2,000 m (800 mbar) (at 25 °C ambient
temperature)
Pollution Degree 2
Operating ambient temperature range 0 °C to 55 °C (Tested in accordance with
IEC 60068-2-1 and IEC 60068-2-2. Meets
MIL-PRF-28800F Class 3 low temperature
limit and MIL-PRF-28800F Class 2 high
temperature limit.)
Operating relative humidity range 10% to 90%, noncondensing (Tested in
accordance with IEC 60068-2-56.)
Indoor use only.
Related Information
Refer to the PXIe-5413 Specifications at ni.com for complete specifications.
Installing the Software
You must be an Administrator to install NI software on your computer.
1. Install an ADE, such as LabVIEW or LabWindows
™
/CVI
™
.
2. Visit ni.com/downloads/drivers and search for NI-FGEN.
3. Download the latest version of NI-FGEN by clicking Download and then running the
executable (.exe) file.
4. Follow the instructions in the installation prompts.
Note Windows users may see access and security messages during
installation. Accept the prompts to complete the installation.
5. When the installer completes, select Restart in the dialog box that prompts you to restart,
shut down, or restart later.
4 | ni.com | PXIe-5413 Getting Started Guide
