Figure 9. Installing a SO-DIMM in a PXIe-8862/PXIe-8862 with Removable Hard Dive Controller
(PXIe-8862 Shown)
1
2
1.
DDR4 SO-DIMM Socket
2.
DDR4 SO-DIMM Module
PXIe-8822/42/62 System Memory Information
NI oers the following types of SO-DIMMs for use with the PXIe-8822/42/62
controller.
■
PXIe-8822/42—16 GB, DDR4 3200 MHz non-ECC SODIMM (NI part number
788899-01)
■
PXIe-8862—2x 16 GB, DDR4 3200 MHz non-ECC SODIMM (NI part number
788900-01)
Note NI has tested and verified that the DDR4 SO-DIMMs listed above
work with the PXIe-8822/42/62 controller. We recommend you purchase
your SO-DIMM modules from NI. Other o-the-shelf modules are not
guaranteed to work properly.
How do I upgrade or replace the storage drive?
NI oers the following types of SSD for use with the PXIe-8822/42/62 controller.
■
PXIe-8822/42/62
