• Mapped network drive—You can use the Ethernet to connect to another
computer. If you share the USB CD/DVD-ROM drive on the other computer, you can
map the shared USB CD/DVD-ROM drive to a drive letter on the PXIe-8822/42/62.
A USB CD/DVD-ROM drive is available from NI (part number 778492-01).
How do I upgrade system memory?
You can change the amount of installed RAM on the PXIe-8822/42/62 by augmenting
or replacing the preinstalled SO-DIMM. Complete the following steps to replace the
RAM.
1.
Remove the PXIe-8822/42/62 from the PXI chassis.
2.
Locate the SO-DIMM sockets on the side of the controller, as shown in the
following figures.
3. Install the new SO-DIMM module into the slot.
Figure 8. Installing a SO-DIMM in a PXIe-8822/42 Controller (PXIe-8822 Shown)
1. DDR4 SO-DIMM Socket
2.
DDR4 SO-DIMM Module
ni.com
28
PXIe-8822/42/62 Getting Started
