© National Instruments Corporation 3 NI sbRIO-961x/9612XT/963x/9632XT/964x/9642XT
Dimensions
This section contains dimensional drawings of the NI sbRIO devices. For
three-dimensional models, refer to the Resources tab of the NI sbRIO
product page at
ni.com.
Note The plated mounting holes are all connected to P1, the ground lug. Connect P1 or
one of the plated mounting holes securely to earth ground. Refer to the Understanding
Ground Connections section for cautions about current loops through the grounding lug.
Figure 2 shows the dimensions of the NI sbRIO-961x/9612XT/963x/
9632XT/964x/9642XT.
