Figure 11. sbRIO-9687 LEDs
User LED
(Red)
User LED
(green)
User LED
(green)
Power LED
(always ON)
For details about troubleshooting the sbRIO-9607 or the sbRIO-9683 or sbRIO-9684 , consult
the related documentation.
If an issue persists after you complete a troubleshooting procedure, contact NI technical
support or visit ni.com/support.
sbRIO-9687 Getting Started Guide | © National Instruments | 15
