• 6-pin signal plug
• 12-pin signal plug
• (QTY 3) 24-pin signal plug
• (QTY 3) 26-pin signal plug
• (QTY 2) 36-pin signal plug
• Aluminum mounting plate
• (QTY 2) Handles
• (QTY 4) 8-32 × 3/8 in. panhead screws (for handles)
• (QTY 9) Standoffs and screws, I/F PCB to Panel, M3 × 43.36 mm M-F, 6 mm Hex,
M3 x 5 mm panhead screws
• (QTY 4) Standoffs and screws, RMC to I/F PCB, M3 x 11.12 mm M-F, 6 mm Hex,
M3 x 5 mm panhead screws
Also included is an OEM kit with an sbRIO-9607 CompactRIO Single-Board Controller, an
sbRIO-9683 or sbRIO-9684 General Purpose Inverter Controller (GPIC), and mounting
hardware:
• sbRIO-9607 controller
• sbRIO-9683 or sbRIO-9684 GPIC
• (QTY 4) Standoffs and screws, M3 × 43.36 mm M-F, 4.5 mm Hex, M3 × 5 mm panhead
screws
1
• (QTY 4) Standoffs, RMC to Panel, M3 × 29.81 mm M-F, 4.5 mm Hex (no screws)
• (QTY 4) Standoffs and screws, M3 × 11.12 mm M-F, 4.5 mm Hex, M3 × 5 mm panhead
screws
1
• (QTY 4) Standoffs and screws, sbRIO to RMC, M3 × 9.65 mm M-F, 4.5 mm Hex,
M3 × 5 mm panhead screws
• sbRIO power cable assembly, mini-fit pigtail, 2C, 12 in.
1
• NI 9683 User Manual and Specifications or NI 9684 User Manual and Specifications
• sbRIO Thermal Kit:
– Heat spreader
– Gap pad
– (QTY 4) Standoff, M3 × 16 mm, M-F, 4.5 Hex
– (QTY 2) Standoff, M3 × 18 mm, M-F, 4.5 Hex
1
– (QTY 6) M3 × 8 mm panhead screws
1
– Thermal Kit for NI sbRIO-9607/9627/9637 Installation and Specifications Manual
1
Some of the mounting hardware included with the OEM kits and the sbRIO Thermal Kit is not
required for this mounting procedure.
sbRIO-9687 Getting Started Guide | © National Instruments | 3
