National Instruments SCXI-1353 User Manual

SCXI-1353 Shielded Cable Assembly 6 ni.com
ACH10 8 8 31
ACH3 9 9 30
ACH11 10 10 63
ACH4 11 11 28
ACH12 12 12 61
ACH5 13 13 60
ACH13 14 14 26
ACH6 15 15 25
ACH14 16 16 58
ACH7 17 17 57
ACH15 18 18 23
AISENSE 19 19 62
DAC0OUT 20 20 22
DAC1OUT 21 21 21
EXTREF 22 22 20
AOGND 23 23 54, 55
DGND 24, 33 24, 33 4, 7, 9, 12, 13, 15, 18,
35, 36, 39, 44, 50, 53
DIO0 25 25 52
DIO4 26 26 19
DIO1 27 27 17
DIO5 28 28 51
DIO2 29 29 49
DIO6 30 30 16
DIO3 31 31 47
DIO7 32 32 48
+5V 34, 35 34, 35 8, 14
Table 1. MIO-16 Cable Connections (Continued)
Signal Names Connector Pin Numbers
100-Pin E Series Device 100-Pin 50-Pin 68-Pin
