National Instruments SCXI-1353 User Manual

© National Instruments Corporation 7 SCXI-1353 Shielded Cable Assembly
SCANCLK 36 36 46
EXTSTROBE* 37 37 45
PFI0/TRIG1 38 38 11
PFI1/TRIG2 39 39 10
PFI2/CONVERT* 40 40 43
PFI3/GPCTR1_SOURCE 41 41 42
PFI4/GPCTR1_GATE 42 42 41
GPCTR1_OUT 43 43 40
PFI5/UPDATE* 44 44 6
PFI6/WFTRIG 45 45 5
PFI7/STARTSCAN 46 46 38
PFI8/GPCTR0_SOURCE 47 47 37
PFI9/GPCTR0_GATE 48 48 3
GPCTR0_OUT 49 49 2
FREQ_OUT 50 50 1
Pins 1 through 9 and pins 35 through 43 on the 68-pin connector are not connected.
Table 2. Extended I/O Cable Connections
Signal Names Connector Pin Numbers
NI 6031E, NI 6033E,
NI 6061E, NI 6071E
NI 6021E, NI 6025E 100-Pin 50-Pin 68-Pin
ACH16 PC7 51 1 68
ACH24 GND 52 2 34
ACH17 PC6 53 3 33
ACH25 GND 54 4 67
ACH18 PC5 55 5 32
ACH26 GND 56 6 66
ACH19 PC4 57 7 65
Table 1. MIO-16 Cable Connections (Continued)
Signal Names Connector Pin Numbers
100-Pin E Series Device 100-Pin 50-Pin 68-Pin
