Optional Items
• LabVIEW Modulation Toolkit (MT), included on the driver software media, which
includes MT VIs and functions, examples, and documentation
Note You must install the LabVIEW Modulation Toolkit for proper operation
of the NI-USRP Modulation Toolkit example VIs.
• LabVIEW Digital Filter Design Toolkit, included on the driver software media
• LabVIEW MathScript RT Module, included on the driver software media
• USRP MIMO sync and data cable, available at ni.com, to synchronize clock sources
• Additional SMA (m)-to-SMA (m) cables to connect both channels with external devices
or to use the REF IN and PPS IN signals
• GPS antenna for devices with GPS disciplined oscillator (GPSDO) support
Preparing the Environment
Ensure that the environment you are using the USRP device in meets the following
specifications.
Operating temperature
23 ±5 °C
Operating humidity 10% to 90% relative humidity, noncondensing
Pollution Degree 2
Maximum altitude 2,000 m
Indoor use only.
Note Refer to the USRP device specifications at ni.com/manuals for complete
specifications.
Caution Do not operate the NI 292x in a manner not specified in this document.
Product misuse can result in a hazard. You can compromise the safety protection
built into the product if the product is damaged in any way. If the product is
damaged, return it to NI for repair.
Installing the Software
You must be an Administrator to install NI software on your computer.
1. Install an ADE, such as LabVIEW.
2. Visit ni.com/info and enter the Info Code usrpdriver to access the driver download
page for the latest NI-USRP software.
3. Download the NI-USRP driver software.
4 | ni.com | NI USRP-2920/2921/2922 Getting Started Guide
