The IP address of the selected device displays in the Selected IP Address textbox.
5. Enter the new IP address for the device in the New IP Address textbox.
6. Click the Change IP Address button or press <Enter> to change the IP address.
The IP address of the selected device displays in the Selected IP Address textbox.
7. The utility prompts you to confirm your selection. Click OK if your selection is correct;
otherwise, click Cancel.
8. The utility displays a confirmation to indicate the process is complete. Click OK.
9. Power cycle the device to apply the changes.
10. After you change the IP address, you must power cycle the device and click Refresh
Devices List in the utility to update the list of devices.
Confirming Network Connection
1. Select Start»All Programs»National Instruments»NI-USRP»NI-USRP
Configuration Utility to open the NI-USRP Configuration Utility.
2. Select the Devices tab of the utility.
Your device should appear in the list on the left side of the tab.
Note If your device is not listed, verify that your device is powered on and
correctly connected, then click the Refresh Devices List button to scan for
USRP devices.
Configuring Multiple Devices with Ethernet
You can connect multiple devices in the following ways:
• Multiple Ethernet interfaces—One device for each interface
• Single Ethernet interface—One device connected to the interface, with additional devices
connected using an optional MIMO cable
• Single Ethernet interface—Multiple devices connected to an unmanaged switch
Tip Sharing a single gigabit Ethernet interface among devices may reduce overall
signal throughput. For maximum signal throughput, NI recommends that you
connect no more than one device per Ethernet interface.
Multiple Ethernet Interfaces
To configure multiple devices connected to separate gigabit Ethernet interfaces, assign
each Ethernet interface a separate subnet, and assign the corresponding device an address
in that subnet, as shown in the following table.
Table 2. Multiple Host Ethernet Interface Configuration
Device Host IP Address Host Subnet Mask Device IP Address
USRP Device 0 192.168.10.1 255.255.255.0 192.168.10.2
USRP Device 1 192.168.11.1 255.255.255.0 192.168.11.2
NI USRP-2920/2921/2922 Getting Started Guide | © National Instruments | 7
