H. Speaker, Analog (line output)
• Connection for a sound field speaker with external amplifier. (Not active on some models.)
I. Line-in
• Connection for a line-in device (e.g. CD player).
Warning • When you connect other electrical equipment to Madsen A450, remember that equipment that does
not comply with the same safety standards as Madsen A450 can lead to a general reduction in the system's safety
level.
J. Operator monitor headset - headphones
• If you are using headphones with the operator monitor headset, plug the headphones into this socket.
The jack is marked with this symbol.
K. Operator monitor headset - boom microphone
• If you are using a boom microphone with the operator monitor headset, plug the boom microphone on the monitor
headset into this socket.
The jack is marked with this symbol.
L. Counseling and Simulations headphones
• Connection for Counseling and Simulations headphones.
M. Talk-back microphone
• Connection for an operator desktop microphone.
The jack is marked with this symbol.
6.6 Assembling Madsen A450
• Read the Otosuite user documentation before you connect or use Madsen A450 for the first time.
Madsen A450 is fully assembled on delivery, and you simply have to connect the cables.
Wall-mount installation
If you wish to mount Madsen A450 on the wall, see Desktop or wall-mount installation ► 76.
6.7 Desktop or wall-mount installation
Install Otosuite on the PC before you connect Madsen A450 to the PC.
76 Madsen A450
6 Unpacking and installing
