35
Replacing the Virtual Pivot
To reduce the risk of electrical shock, always unplug the power cord and wait 5 minutes before cleaning, maintaining or repairing this machine.
Tools Required: #2 Phillips Screwdriver, (2) 13 mm wrenches, 5 mm hex wrench, 4 mm hex wrench
1. Follow Treadle Assembly Removal procedures to remove Treadle Assembly. THIS STEP REQUIRES TWO PEOPLE.
2. Remove the Drive Pulley using two 13 mm (1/2”) wrenches.
3. Loosen the Belt Tensioning Screws on both Treadles using 5 mm hex wrench
(total of 4 screws).
