Nautilus ONE Owners Instructions And Assembly

COLOR
TOWER
DESCRIPTION
Green
WT-L-250-1
250 lb with 1 lb add-on, range limiter
Yellow
WT-L-250-5
250 lb with 5 lb add-on, range limiter
Neon Red
WT-SYS-250-1
250 lb with 1 lb add-on
Neon Orange
WT-SYS-250-5
250 lb with 5 lb add-on
Dark Blue
WT-SYS-385-5
385 lb with 5 lb add-on
Neon Yellow
WT-SYS-425-5
425 lb with 5 lb add-on
Black
WTM-L-125-0.5
125 kg with .5 kg add-on, range limiter
Orange
WTM-L-125-2.5
125 kg with 2.5 kg add-on, range limiter
Red
WTM-SYS-125-0.5
125 kg with .5 kg add-on
Neon Green
WTM-SYS-125-2.5
125 kg with 2.5 kg add-on
No Color
WTM-SYS-185-2.4
185 kg with 2.4 kg add-on
Light Blue
WTM-SYS-200-
2.4
200 kg with 2.4 kg add-on
TOWER
SEAT FRAME
Figure 1
Color-Coded Installation
All Nautilus
®
ONE
®
seat frames and weight towers are color-coded for easy installation. Match
the colored decal on the seat frame to the same colored decal on the weight tower for the
proper fit. Refer to Figure 1 below for all of the possible color combinations.
If you have any questions or concerns regarding installation of the Nautilus
®
ONE
®
system,
please contact a Core Fitness Customer Excellence representative at 800-235-2233, or
276-773-2881 outside the United States.
5
