19
DXP1000DVR
2-Way DualMirror™ Operation
Cable Number Devices Product Description Wire Length
SL55A Android 5-pin microUSB connector to HDMI + US
ft
SL113A Android 11-pin microUSB connector to HDMI + US
ft
SL115A Android 11-pin microUSB connector to HDMI + US
ft
DL5i iOS HDMI cable & USB cabl
ft
Mirror Link
1. Click QR code icon on HOME screen on page 3.
2. When QR code shows up, scan the QR code on the Android phone
.
3. Download DualMirror.apk from Google Play Store.
4. When the download is complete, the DualMirror APP icon is
created on main menu.
5. Select DualMirror App installed in the Android phone.
6. Tap OPEN BT SETTING to move to Bluetooth setting mode
7. Pair the Android phone with the unit via Bluetooth.
8. Connect Android phone to the unit using the Dual SL cable or using
wireless screen mirroring and DMH25 dongle.
9. Select DUAL MIRROR Mode.
10. Tap ACCEPT on Warning screen.
Note : If the 2-way control is not working, verify that the DualMirror
running prior to connecting the phone to the unit and make
re that the Bluetooth is paired/connected and the status on the
ys "Connected".
Remark:
For the 2-way control feature, here is how to setup and connect your Android device.
*. Currently IOS is not compatible for 2-way control.
The DualMirror technology requires the following cables which are sold separately.
TM
The DualMirror technology allows you to mirror the screen of select Android smartphones as
well as iPhone, iPod and IPad devices onto the receiver’s screen and to charge your mobile device
through the front USB port. Simply plug in your device to the front HDMI and USB inputs,
and you
are ready to view
your favorite navigation or music apps directly on the receiver’s screen.
Wireless WiFi Android/Video and Mrroring Dongle
For Android/
iOS devices
DMH25
Note: For wireless mirorring, Android phones must support Miracast to work. Please check your
phone manufacturer's specifications for compatibility. Apple Airplay/Mirorring is supported.
To Next Page
