20
Product
Name NAVEE Electric Scooter
Model K2A-N30AE
Dimensions
Vehicle: L × W × H (mm)
[1]
1135 x 500 x 1172
After Folding: L × W × H (mm) 1135 x 500 x 475
Net Weight Vehicle Net Weight (kg) 13.8
Rider
Load Range (kg) 25-100
Age (years) 16-50
Body Length (cm) 120-200
Assembled Electric
Scooter
25
General Range (km)
[2]
Approx. 30
Max. Climbing Angle (%) Approx. 20
Suitable Surfaces
Cement or asphalt road, with benches of less than 1 cm or crevices narrower
than 3 cm
Operating Temperature (° C) -10 to 55
Storage Temperature (° C) 0 to 45
IP Rating IPX4
Charging Time (h) Approx. 5-6
Battery Pack
Model VICTg10S3PYBb250002
Nominal Voltage (VDC) 36
Max. Charge Voltage (VDC) 42.5
Rated Energy (Wh) 270
Intelligent Battery
Management System
Over-heating, short circuit, over-current, over-discharge, and over-charge
protection
Normal Charging
Temperature Range (° C)
0 to 45
Rated Capacity (Ah) 7.5
Wheel Motor Rated Power (kW; W) 0.3; 300
Battery Charger
Output Power (kW; W) 0.063; 63
Input Voltage (VAC) 100–240
Max. Output Voltage (VDC) 42.5
Rated Output (VDC; A) 42.0; 1.5
Model
[3]
FY0684201500
Tire Front & Back Tires 10-inch pneumatic tire
Bluetooth
Frequency Band (s) 2.4000–2.4835 GHz
Max. RF Power (dBm) 8
1. Vehicle height: From the ground to the top of the scooter.
surface with a load of 75 kg.
scooter is
