24
WM-4 Marine Weather & Audio Receiver Installation Manual
FCC Statement
The user is cautioned that changes or modifications not expressly
approved by Navico Inc. or Sirius XM Radio Inc. can void the user’s
authority to operate this device. This device complies with Part 15 of the
FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the installation
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna of the affected receiver.
• Increase the separation between the Navico or SiriusXM equipment
and the affected receiver.
• Connect the Navico or SiriusXM equipment into an outlet on a
circuit different from that to which the affected receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
IC Information
Warning: Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the equipment.
Canadian Compliance: This Class B digital apparatus complies with Canadian
ICES-003.
IC STATEMENT
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device. For product
available in the Canada market, only channel 1~11 can be operated. Selection
of other channels is not possible. This device and its antenna(s) must not be
co-located or operation in conjunction with any other antenna or transmitter.
To reduce potential radio interference to other users, the antenna type and
its gain should be so chosen that the equivalent isotopically radiated power
(e.i.r.p) is not more than that permitted for successful communication. IC
Radiation Exposure Statement: This equipment complies with IC RSS-102
radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
Specifications
WM-4 Receiver
Dimensions ...................7 in (W) x 3.1 in (H) x 1.7 in (D)
180 mm (W) x 80 mm (H) x 42 mm (D)
Weight .......................
9.63
oz (273 g)
Nominal Supply Voltage ........12v or 24v DC
Operating Voltage Range ........10.8v to 31.2v DC
Power Consumption ............<3.0W
Operating Temperature .........-4°F to +158°F (-20°C to +70°C)
Waterproof Rating .............IPX 6/7
Antenna Connection ............SMA (SMA to SMB adapter included
Network Connection ............TCP/IP over Ethernet (10/100-Base-TX)
Static IP: 172.22.255.252
Gateway: 172.22.251.1
Subnet Mask: 255.255.255.0
Audio Connection ..............Stereo Analog Audio Out, 2v RMS
Power Connection ..............2-Wire Switched B+ and Ground, plus
RF Ground
Antenna
Type .........................SiriusXM approved Marine Antenna
Pigtail Cable ...................6 in (152 mm), TNC Female
Antenna Cable .................25 ft (7.6 m), TNC male to SMB
Cables
Network Cable Length ..........8 ft (2.5 m) 7-pin to RJ45
Waterproof Rating ............Cable Connectors IPX 6/7
Power Cable Length ............6.5 ft (2 m), Fuse 5.0 A, AGC
Waterproof Ratings Cable C onnector IPX 6/7, Fuse Holder
IPX 5
Audio Cable Length ............6.5 ft (2 m)
Waterproof Rating ............IPX 6/7
Network Operation ...............XM Network
Specifications are subject to change without notice.
