EL connection diagram:
Overview of connectivity.
IN OUT
230 PE-N-L 230Volt AC
SAFETY THERMOSTAT L-L Safety thermostat cutoff
MOTOR PE-N-L1 External auger
BRÆNDER PE-N-L2 Fan
BRÆNDER PE-N-L3 Internal auger
BRÆNDER PE-N-L4 Ignition
EKSTRA 1 PE-N-L5 Circulation pump, can be set to other equipment.
EKSTRA 1 PE-N-L6 Compressor cleaning, can be set to other equipment.
EKSTRA 2 PE-N-L7 De-ashing Auger.
EKSTRA 2 PE-N-L8 Optional output for equipment.
EKSTRA 3 PE-N-L9 Boiler Compressor Valve 1
EKSTRA 3 PE-N-L10 Boiler Compressor Valve 2
BUS GRD, TX, RX, Expansion module
ILT V1, V, V2 O2 controller
KONTAKT K-K1 External ON/OFF
KONTAKT K-K2 Free
PULS P-P1 Flow meter system
PULS P-P2 Flow meter solar heating
PULS P-P3 Free
PULS P-P4 Fan RPM
AFSTAND -, SIG, + Distance sensor for hopper
LAN RJ45 Internet connection
TEMP. T- T1 Boiler temperature
TEMP. T – T2 Smoke temperature
TEMP. T – T3 Boiler return temperature
TEMP. T – T4 DHW temperature
TEMP. T – T5 External temperature
TEMP. T – T6 Free
TEMP. T – T7 Free
EKS / FOTO T – T9 Temperature sensor burner
EKS / FOTO T-T10 Photo sensor burner
