NBE RTB - RTB Pellet Hoppers

RTB Pellet Hoppers
More pellet hopper solutions can be found at www.nbe-global.com .
All hoppers can be used for the vacuum transporting of pellets to the hopper.
120kg:
Hopper Width 300 mm
Width (Boiler+ Hopper) 806 mm
Height 1300 mm
Depth 845 mm
Pellet Capacity: 120 kg
Compatible with RTB sizes: 10,16, & 30 kW
220kg:
Hopper Width 500 mm
Width (Boiler+ Hopper) 806 mm
Height 1300 mm
Depth 845 mm
Pellet Capacity 220 kg
Compatible with RTB sizes: 10,16,& 30 kW
320kg:
Hopper Width 700 mm
Width (Boiler+ Hopper) 806 mm
Height 1300 mm
Depth 845 mm
Pellet Capacity 320 kg
Compatible with RTB sizes: 10,16,& 30 kW
VAC10/16:
Hopper Width 506 mm
Width (Boiler+ Hopper) 606 mm
Height 1827 mm
Depth 845 mm
Pellet Capacity 50 kg
Compatible with RTB sizes: 10 & 16 kW
Vacuum Transport is included.
VAC30:
Hopper Width 606 mm
Width (Boiler+ Hopper) 606 mm
Height 1827 mm
Depth 845 mm
Pellet Capacity 70 kg
Compatible with RTB sizes: 30 kW
Vacuum Transport is inculded.
