Optional Equipment:
The controller supports the following equipment.
Aids in performing adjustments, cleaning, and knowledge.
INCLUDED WITH RTB
Smoke temp. sensor:
Reads the current smoke
temperature in the display.
O2 control kit:
Regulates the amount of
oxygen in the flue gas.
Regulates the quantity of
wood pellet and air
according to the desired
O2%.
Hot Water Priority kit:
Produces hot water only
when it is needed. Closes
hot water tank, when the
house is heated. Kits
available with either 2 or 3
way motorized valve.
INCLUDED Compressor
Cleaning System: Cleans
the burner head efficiently
with high pressure. With
this kit you need to use
your own compressor.
INCLUDED WITH RTB
Compressor :
Clean the burner head
efficiently with high
pressure. With “low noise”
compressor.
Solar heating
Use the pellet burner
controller to run your solar
system.
External temp. sensor:
Stops burner through an
external temperature sensor.
Flow sensor kit:
Read the system flow in the
display and calculates the
current power consumption
for the house.
Distance sensor for hopper:
See how much is left in the
hopper and displays it on the
controller screen.
Exhaust fan:
Need greater chimney draft?
The fan’s RPM can be
synched with the burner's
power output.Can be
connected to the burner
controller.
Weather compensating:
Maintains a high boiler
temperature and adjusts the
house inlet temperature in
relation to the outdoor
temperature.
Wireless thermostat:
Stops the pellet burner with
thermostat.
Gives a smooth transition to
summer time.
