13
Technical Specifications
Engine Torque Figures
Item Torque Setting Angle
Nm lbf ft
Inlet manifold retaining bolts 22-26 16-19 -
Item Torque Setting Angle
Nm lbf ft
High pressure fuel pipes 25-29 19-22 -
Item Torque Setting Angle
Nm lbf ft
Power take off (PTO) pump bolts
- SAE ‘A’ - M10 bolts 43-51 32-38 -
- SAE ‘B’ - M12 bolts 73-89 54-66 -
Item Torque Setting Angle
Nm lbf ft
Lifting bracket retaining bolts 43-51 32-38 -
