Page 10 of 16
Data sheet .
1 Key Facts
Technical
Distinctive features
 Nominal torque: up to 500 Nm,
bidirectional
 Speed: ≤ 5000 rpm
 Accuracy: ≤ ±1 %
 Operating temperature: -30 °C to +85 °C
 Protection class: IP50
 Output signal: 0-5 V
 Cut-off frequency: 1.000 Hz
 Made in Germany
 Short delivery time (< two weeks)
 Excellent price/performance ratio
 No external measuring amplifier necessary
(Plug & Play)
 Completely contactless measuring system
 Delivery including 5 m cable and calibration
certificate
 Suitable accessories (bracket, readout unit,
couplings)
2 Torque ranges
Model line
Series 2100
Square shaft
Nominal torque
bidirectional
(+/-) [Nm]
Limit torque
unidirectional
[Nm]
Limit torque
bidirectional
(+/-) [Nm]
RPM
[rpm]
¼ inch
2.5
2.5
2.5
1000
(A higher speed is
possible with
backlash-free
adaptation)
5.0
5.0
5.0
7.5
7.5
7.5
17.5
15
10
⅜ inch
75
60
40
½ inch
175
140
85
¾ inch
500
400
270
Note: Series 2100 sensor versions are calibrated to nominal torque. However, the absolute operating limits
are as shown in the table above. Do not exceed the specified magnitude of the limit torques for unidirectional
and bidirectional loading.
Model line
Series 2200
Round shaft
Nominal torque
bidirectional
(+/-) [Nm]
Limit torque
unidirectional
[Nm]
Limit torque
bidirectional
(+/-) [Nm]
RPM
[rpm]
Ø 9 mm
2.5
3.25
3.25
5000
5
6.5
6.5
7.5
9.75
9.75
17.5
19.5
19.5
Ø 14 mm
75
97.5
97.5
Ø 19 mm
175
227.5
227.5
250
325
325
Ø 25 mm
500
650
650
Note: In case of overload, the sensor leads to a measurement offset. In this case the sensor must be
recalibrated at NCTE AG. The sensor may only be operated within the specified nominal torque range.
