NCTE 2000 Series - EMV Emission data

_______________________________________________________________________________________
_______________________________________________________________________________________
Page 12 of 16
5 EMV Emission data
EMV immunity and emitted interference (DIN EN IEC 61000-6-2 / DIN EN IEC 61000-6-4 / DIN EN 61326-1)
Examination
Test specification
Admission
Evaluation criteria
Discharge of static
electricity (ESD)
IEC 61000-4-2
± 4 kV Contact
discharge
B
passed
Electromagnetic HF-
field
IEC 61000-4-3
80 - 1000 MHz; 10 V/m;
80% AM
A
passed
Rapid transients
IEC 61000-4-4
± 1 kV
B
passed
High frequency,
asymmetrical
IEC 61000-4-6
0.15 - 80 MHz; 10V;
80% AM
A
passed
Examination
Test specification
Admission
Evaluation criteria
Interference voltage
0.15 - 30 MHz
CISPR 11:2015 +
A1:2010
Class B
Limit values observed
Radio interference field
strength
30 - 1000 MHz
CISPR 11:2015 +
A1:2010
Class B
Limit values observed
6
Wiring connected.
Effect of temperature
Unit
Value
11
Zero point drift over temperature
%/10 K
< 0.5
12
Signal drift over temperature
within nominal temperature range
%/10 K
< 0.5
Power supply
Unit
Value
13
Supply voltage
VDC
6 … 15
14
Current consumption (max.)
mA
10
15
Start-up peak
mA
< 40
16
Absolute max. supply voltage
VDC
18
General information
Unit
Value
17
Protection class according to EN
60529
6
IP
50
18
Reference temperature
°C
+15 … +35
19
Operation temperature range
°C
-40 … +85
20
Storage temperature range
°C
-40 … +85
Nominal torque
(bi-directional) Square shaft
Nm
2.5
5
7.5
15
75
175
250
500
21
Weight
g
395
401
414
652
754
878
22
Moment of inertia
g mm
2
582
648
904
3.339
13.294
57.770
Nominal torque (bidirectional)
Round shaft
Nm
2.5
5
7.5
15
75
175
250
500
23
Weight
g
386
392
400
685
856
1.230
24
Moment of inertia
g mm
2
597
662
1.073
4.922
19.126
79.754
