3 Load characteristics
Model line Series 2100
Measuring range
Axial force [N]
1
Limit transverse
force [N]
Limit bending moment
[Nm]
2.5 and 5
1000
20
2.5
7.5
1000
30
3.7
17.5
1000
100
12.5
75
2600
300
41.7
175
4000
500
89.5
500
7000
800
176
Model line Series 2200
Measuring range
Axial force [N]
2
Limit transverse
force [N]
Limit bending moment
[Nm]
2.5 and 5
1000
20
2.5
7.5
1000
30
3.7
17.5
1000
100
12.5
75
2600
300
41.7
175 and 250
4000
500
89.5
500
7000
800
176
Any irregular stress (bending moment, transverse or axial force, exceeding the nominal torque) up to the
specified static load limit is only permissible as long as none of the other stresses can occur. Otherwise the
limit values must be reduced. If 30 % of the limit bending moment and 30 % of the limit transverse force are
present in each case, only 40 % of the axial force is permissible, whereby the nominal torque must not be
exceeded.
4 Technical characteristics
1
Specified values only apply to direct axial force on the shaft. If the axial force acts on the circlip, only 50 % of the force is permissible.
2
Specified values only apply to direct axial force on the shaft. If the axial force acts on the circlip, only 50 % of the force is permissible.
3
The accuracy class means that the linearity deviation as well as the circulation modulation, individually, are each less than or equal to the value
specified as the accuracy class. The accuracy class must not be confused with a classification according to DIN 51309 or EA-10/14.
4
%ME: Related to the measuring range.
5
The exact sensor-specific values can be found in the calibration certificate supplied.
No.
Accuracy class
3
1,0
Description
Unit
Value
1
Linearity deviation incl. hysteresis
%ME
4
< ±1.0
2
Rotational Signal Uniformity (RSU)
< ±1.0
3
Repeatability
< ±0.05
Output signal general
Unit
Value
4
Cut-off frequency, -3dB point,
Bessel characteristic
Hz
1000
5
Analog signal
V
0 … 5
6
Signal at torque = zero
5
V
2.5
7
Signal at positive nominal torque
5
V
4.5
8
Signal at negative nominal torque
5
V
0.5
9
Calibration parameter (normed)
5
mV/Nm
Refer to calibration certificate
10
Output resistance
Ω
50
