2030434-006 Rev. E EasyOne-CS Field Service Manual Page 8
Temperature: 0 to 40 °C
Relative humidity: 0% to 95%
Ambient pressure: 500 to 1060 hPa
Certifications and standards:
CE Declaration of Conformity
C CSA US approval, CAN/CSA-C22.2 No. 601.1-M90, S1-94, CSA 601.1
Amendment 2:1998, UL Std No. 2601.1
FDA 510 (k) approval, K993921
EasyOne-CS meets or exceeds the published targets of the European
Respiratory Society (ERS), the American Thoracic Society (ATS) and the
National Lung Health Education Program (NLHEP).
Instrument classification:
Type BF applied part (when used with a PC, protection class 2
according to IEC 60601-1)
Instrument not suitable for use in flammable anesthetic gases in mixtures
with O
2
or NO.
6.2 EasyOne-CS Model 2010 Screen-Connector
64 x 44 x 25 mm (2.5 x 1.7 x 1.0 inches)
Connects the EasyOne-CS spirometer to a PC
Standard USB type A connector for connection to PC
Pins: 1 = VBus, 2 = D–, 3 = D+, 4 = GND
Temperature: -20 to 50 °C
Relative humidity: 5% to 95%
Ambient pressure: 500 to 1060 hPa
Temperature: 0 to 40 °C
Relative humidity: 0% to 95%
Ambient pressure: 500 to 1060 hPa
The PC must comply with corresponding IEC standard (ex. IEC 60950-1. The
user is responsible that requirements of IEC 60601-1-1 for safety of medical
electrical systems are met.
7 Replacement Parts List
The following parts are available for replacement:
7.1 Manuals
Part Number
Short Description
2030434-006 MNL SVCE EASYONE-CS
Field Service Manual (this document)
Operator’s Manual English
Operator’s Manual Italian
Operator’s Manual Spanish
Operator’s Manual Portuguese
Operator’s Manual English-US
