2030434-006 Rev. E EasyOne-CS Field Service Manual Page 18
11.6 EasyOne-CS Device Software Update Procedure
In order to update the EasyOne-CS device software follow this procedure:
1. Connect the EasyOne-CS Screen-Connector with an unused USB port of your PC.
2. Turn the power of EasyOne-CS on and connect it with the ScreenConnector. The EasyOne-CS
display shows: „EasyOne“.
3. Start the PC software “EasyFlash”.
4. Set “Device Selection” to “EasyOne” and communication port to “Screen Connector”.
5. Press the “Update Device Info” button. The window on the right side shows the Model and the
version information of the EasyOne-CS.
6. The device software can be selected through selecting the “Open” icon or with menu command
“File/Open” C:\nddmed\2033231-008\ EasyOne-CS V4.3 Firmware EU\GE-EOV04030000-P-
EU_Resources.hex”).
7. The programming is started by pressing the “Download” button. You are requested to enter
your company and user name.
8. Under certain circumstances the following message can appear.
In order to procede perform the following steps.
a. Click “OK”.
b. Disconnect EasyOne-CS from the ScreenConnector. The display of EasyOne-CS shows
“Receive Idle mode, Setting 19200 Baud”.
c. Reconnect EasyOne-CS with the ScreenConnector
d. Click “Update Device Info” and press the “Download” button again.
9. During the programming of EasyOne-CS a progress bar is shown. The programming takes
approx. 3 to 5 minutes. Please do not interrupt the programming process. After successful
programming the following message is shown:
10. The EasyOne-CS device has to be restarted using the ON/OFF key.
