6. charging curve
selection
The Dip Switches, located next to the power
connections, allow you to select the proper charging
curve for the installed services battery, use the table to
set the correct curve for your battery. The Dip Switches
affect the B1 charging curve (leisure battery), not B2
(starter battery). The B2 charging curve is preset to
curve N°4 (wet - desulphation OFF).
8
CURVE
NUMBER
SWITCH SETTING
CURVE TYPE
CHARGING DATA
0
GEL
Desulphation OFF
1
GEL
Desulphation ON
2
AGM
Desulphation OFF
3
AGM
Desulphation ON
4
Wet
Desulphation OFF
5
Wet
Desulphation ON
6
LiFePO
4
Lithium
Maintenance OFF
7
LiFePO
4
Lithium
Maintenance ON
1 = OFF
2 = OFF
3 = OFF
1 = OFF
2 = OFF
3 = ON
1 = OFF
2 = ON
3 = OFF
1 = OFF
2 = ON
3 = ON
1 = ON
2 = OFF
3 = OFF
1 = ON
2 = OFF
3 = ON
1 = ON
2 = ON
3 = OFF
1 = ON
2 = ON
3 = ON
Vmax = 14,3V
Vmaint = 13,6V
Vmax = 14,8V
Vmaint = 13,8V
Vmax= 14,4V
Vmaint = 13,5V
Vmax = 14,3V
Vmaint = 13,6V
Vdes= 15,8V
Vmax= 14,8V
Vmaint = 13,8V
Vdes = 15,8V
Vmax= 14,6V
Vmax= 14,6V
Vmaint= 13,7V
Vmax= 14,4V
Vmaint = 13,5V
Vdes = 15,8V
off off off
1 2 3
off off on
1 2 3
off
1 2 3
ON off
off
1 2 3
ON on
1 2 3
offON off
1 2 3
ONoffon
1 2 3
ON on off
1 2 3
ON on on
NOTE
• The default setting is Curve 0, for GEL batteries - desulphation
OFF.
• In order to safeguard the battery, with an ambient temperature
below 0°C, the LiFePO
4
charge curve will not be started.
