www.neatech.it

95/126

Central mounted legrest

Figure 78

• Remove footplates. See section 5.6.10

• Unscrew the screws shown in figure using a allen

wrench while holding the nut behind with a open-end

wrench.

• Substitute footplate fixing system and mount the old

footplate.

ALLEN WRENCH

5 mm

OPEN-END

WRENCH

13 mm

Code

Description

Type of

operation

Notes

R045-0321A

Fixing system for footrest - LEFT side unique

footplate

R045-0321B

Fixing system for footrest - RIGHT or LEFT side

splitted footplates or RIGHT side unique footboard

R045-0321C

Fixing system for footrest - central mounted

legrest
