• To use the system, maneuver the wheelchair slowly and in a uniform direction over the
docking station. The lock plate under the wheelchair helps to guide the wheelchair into place
in the docking station. When the lock plate is fully engaged in the docking station, a spring-
action locking pin automatically secures the lock plate.
• The docking station is equipped with a control switch that indicates whether the lock plate
is correctly secured in the docking station. As soon as the lock plate comes into contact with
the locking pin, a warning tone will sound and the red led in the control panel will light up
until the lock plate is either fully engaged or else the wheelchair is removed from the docking
station. As an indication that the wheelchair is properly secured, the warning tone will cease,
the red diode in the control panel will go out and the green led will light up.
• When the wheelchair is correctly secured, the safety belt should be fitted and adjusted so
that it fits the user.
• UNLOCKING PROCEDURE. When the vehicle has been brought to a halt, remove the safety
belt. To unlock commence by driving the wheelchair forward to release pressure on the lock
pin and then press the red release button in the control panel. The locking pin will be
triggered/released for approx 5 seconds, after which the locking pin is automatically
locked/activated again. Do not attempt to reverse out the docking station until the red LED
on the control module, which indicates the unlock position, has been illuminated. Move the
wheelchair away from the docking station within this 5-second period.
