www.neatech.it
57/126
4.6 Battery charging
In order to recharge batteries, use only the provided charger or one recommended by the
manufacturer. The manufacturer is not responsible for any damage to person or objects
resulting from the use of non-original product.
CHARGER SPECIFICATION
24 V -MIN 6 A MAX 10 A - Charge profile for AGM batteries
• Connect the power cord to a power supply 230 V.
• Connect the cable to the joystick as shown in Figure.
Figure 47
• When batteries are loaded unplug the power cord and the battery cable from the joystick.
RUNNING-IN PERIOD
Typically, batteries are able to offer 100% performance after about 15-20
cycles.
BATTERIES SPECIFICATION
Seat width from 300 mm to 360 mm: 24 V - 35 Ah - about 197x131x180 (h)
mm - about 11 kg
Seat width from 380 mm to 460 mm: 24 V - 50 Ah - about 198x166x171 (h)
mm - about 15 kg
