www.neatech.it
98/126
5.6.12 Backrest actuator
Average needed
time:
5 min
Difficulty level:
Easy
Figure 82
• Remove the axis shown in figure.
• Unscrew the screw shown in figure.
• Unplug the actuator.
• Substitute the actuator.
ALLEN WRENCH
6 mm
