Neatech Rehab Series User Manual

www.neatech.it
20/126
RIGHT AND LEFT SIDE
It is possible to adjust separately left and right legrest if you have splitted
footrest.
INFORMATION
With calf supports, it is possible that some footplates heights can't be
reached.
Average needed
time:
<5 min
Difficulty level:
Easy
Figure 12
• Unscrew the screw shown in figure with the allen
wrench while holding the nut behind with the open-
end wrench.
• Repeat the operation for both left and right side of
the wheelchair.
• Set the position of the footplate according to
desired height.
• Screw again the screws.
ALLEN WRENCH
5 mm
OPEN-END WRENCH
13 mm
