www.neatech.it
23/126
Angle adjustment
Figure 14
• Loosen the 2 screws shown in figure.
• Set the position of the footplate according to desired angle.
• Tighten again the screws.
ALLEN WRENCH
4 mm
Central mounted legrest
Figure 15
• Loosen the screw shown in figure to lower the footplate. Tighten
it to rise the footplate.
ALLEN WRENCH
4 mm
