Neato Robotics D9 User Manual

5
ENGLISH
Preparing to use your Neato robot
Before you start using your Neato, perform
the setup instructions in this chapter.
Positioning the charge base
Before positioning the charge base, select
a clear area with good Wi-Fi coverage.
Begin by inserting the plug behind the charge
base into an AC outlet. Shorten the cord as needed
by wrapping it behind the charge base.
Make sure the charge base is against the wall and
plugged in securely.
Place Neato against the charge base. When
docked properly, the battery LED on the robot
vacuum lights up.
12”
12”
12”
Checking the battery
Your Neato battery comes partially charged. Before
you use your Neato for the first time, position it at the
charge base and allow the robot to charge until the
battery LED becomes green (up to 3 hours).
NOTE: Always charge your Neato using the supplied
Neato Original charge base and battery.
Auto recharge and resume
If the area to be cleaned is very large, your Neato may
need to recharge its battery before finishing the job.
Once recharged, it will return to finish where it left o.

Neato Robotics D9 Specifications

General

Shape	D-shape
Product color	Black
Dust container type	Dust bag
Brush type	Roller brush & Side brush
HEPA class	HEPA 11
Noise level	- dB
Wet mopping	No
Number of brushes	2
Integrated sensors	Drop sensor
Programming function	Yes
Vacuum air filtering	HEPA
Dust capacity (total)	0.7 L
Base station functions	Charging
Vacuum cleaner programs	Turbo
Floor surfaces supported	Carpet, Hard floor, Laminate, Linoleum, Parquet, Tiles, Wood
Battery capacity	4200 mAh
Package type	Box
Package width	450 mm
Package height	160 mm
Package weight	5500 g

Weight and Dimensions

Depth	100 mm
Width	340 mm
Height	330 mm
Weight	3700 g
