USER GUIDE
DTH-1-1 (BK) TEL
WALL MOUNTING TEMPLATE
82mm
UP
LAST NUMBER REDIAL
1. Lift Handset.
2. Press REDIAL Key to dial the last # dialed.
Note : If you disconnect the phone from the network, redial memory will be
erased in a few hours.
WALL MOUNTING
The DTH-1-1 (BK) TEL is suitable for wall mounting. Check for hidden cables, water
pipes, etc. before drilling holes. Before you commence, check that the intended
mounting point is within reach of a Telephone Socket.
1. Use the template to mark the position of the two screws (not supplied) which will
secure the DTH-1-1 (BK) TEL in position.
2. Drill the holes.
3. Fit the screws (not supplied) to the wall, leaving 3.3 mm sticking out (use wall
anchors if necessary, not supplied).
4. Place the two holes on the base of the telephone over the installed screws, then
slide into place.
Note: When the DTH-1-1 (BK) TEL is wall
mounted, the hanger hook (with
serrated top) is located on the base.
Rotate 180 degrees (so the lip
protrudes) and replace.
