3
TV AND A
TV AND A
V
V
RCA JACK A
RCA JACK A
V (BACK)
V (BACK)
Connecting external equipment
Use the TV/VIDEO button on the remote control or on the front of the
set to select one of the two options. Whenever the TV/VIDEO button
is pressed, the on-screen display will be changed as shown:
AV TV
A/V OUTPUT (RCA JACK)
This provides alternately the TV signal output of the selected channel,
or another AV input signal. If the TV set displayed RF signal, A/V
output is RF signal. And, if the TV set displayed AV input signal, A/V
output is AV input signal.
This is used to connect a VCR for recording or a monitor device for
displaying.
This is used to connect VCR or DVD player. Press TV/VIDEO button to change
from the TV mode to AV mode or vice versa.
