E-32
INSTALLATION AND CONNECTIONS
⬎
Making Connections
RGB OUT
Connecting an External Monitor
You can connect a separate, external monitor to your projector to simulta-
neously view on a monitor the RGB analog image you're projecting. To do
so:
1. Turn off the power to your projector, monitor and computer.
2. Use a 15-pin cable to connect your monitor to the RGB OUT (Mini D-Sub
15 pin) connector on your projector.
3. Turn on the projector, monitor and the computer.
NOTE: The RGB OUT connector outputs RGB signal during idle mode (See page
E-100). When the projector goes into idle mode, the image on an external monitor
disappears for a moment. Note that the RGB OUT connector will not output RGB
signal during Stanby mode.
• Daisy chain connection is not possible.
