NEC M402W - Terminal Panel Features

9
1. Introduction
Terminal Panel Features
1246
14
13
7
98
1211 10 35
1. COMPUTERIN/ComponentInputConnector
(MiniD-Sub15Pin)
(→page121, 123, 125)
2. COMPUTERAUDIOINMiniJack(StereoMini)
(→page121, 123, 125)
3. HDMI1INConnector(TypeA)
(→page121, 126)
4. HDMI2INConnector(TypeA)
(→page121, 126)
5. USB-BPort(TypeB)
(→page44, 45)
6. MONITOROUT(COMP.)Connector(MiniD-Sub
15Pin)
(→page123)
7. AUDIOOUTMiniJack(StereoMini)
(→page123)
8. VIDEOINConnector(RCA)
(→page124)
9. VIDEOAUDIOINL/MONO,R(RCA)
(→page124)
10.MICInputJack(MonauralMini)
(→page71)
11.LANPort(RJ-45)
(→page127)
12.USB-APort(TypeA)
(→page74)
13.3DSYNC(MiniDIN4Pin)
(→page67)
14.PCCONTROL[PCCONTROL]Port(D-Sub9Pin)
(→page146)
 UsethisporttoconnectaPCorcontrolsystem.This
enablesyoutocontroltheprojectorusingserialcommu-
nicationprotocol.Ifyouarewritingyourownprogram,
typicalPCcontrolcodesareonpage146.
