2. Projecting an Image (Basic Operation)
❻ Correcting Keystone Distortion Manually
Ifthescreenistiltedvertically,keystonedistortionbecomeslarge.AutomaticKeystoneCorrectionfunctionisturnedon
atthetimeofshipment.Tocorrectkeystonedistortionmanually,proceedwiththefollowingstepstocorrectkeystone
distortion.
NOTE:
• TheKeystonecorrectioncancauseanimagetobeslightlyblurredbecausethecorrectionismadeelectronically.
• TheKeystonecorrectionrangecanbemadenarrower,dependingonasignaloritsaspectratioselection.
[M352WS/M302WS/M332XS]
Adjusting with buttons on the cabinet
1. Press the ▲ or ▼buttonwithnomenusdisplayed.
 Thekeystonebarwillbedisplayed.
2. Use the ▲ or ▼tocorrectthekeystonedistortion.
 Thekeystonebarwillbeclosedafteraperiodoftime.
3. Press the ENTER button.
 Thekeystonebarwillbeclosed.
NOTE:
• Whenthemenuisdisplayed,theaboveoperationisnotavailable.Whenthemenuisdisplayed,presstheMENUbuttontoclose
themenuandstarttheKeystonecorrection.
 Fromthemenu,select[SETUP]→[GENERAL]→[KEYSTONE].Thechangescanbesavedwith[KEYSTONESAVE].(→page
94)
• Keystonecontrolisnotavailablewiththe▲or▼buttonwhenthe[USB-B]inputisused.
