6. Installation and Connections
[M353WS/M303WS]
Thefurtheryourprojectorisfromthescreenorwall,thelargertheimage.Theminimumsizetheimagecanbeisap-
proximately60"(1.52m)measureddiagonallywhentheprojectorisroughly22inches(0.6m)fromthewallorscreen.
Thelargesttheimagecanbeis150"(3.8m)whentheprojectorisabout58inches(1.5m)fromthewallorscreen.
150"
120"
Distance
(Unit: m/inch)
Lens center
Screen Size
1.2/46.3"
1.5/58.3"
1/38.3"
0.8/30.3"
0.6/22.2"
Screen Size (Unit: cm/inch)
323.1(W)�201.9(H) / 127(W)�79(H)
258.5(W)�161.5(H) / 102(W)�64(H)
100"
80"
60"
215.4(W)�134.6(H) / 85(W)�53(H)
172.3(W)�107.7(H) / 68(W)�42(H)
129.2(W)�80.8(H) / 51(W)�32(H)
TIP:
• DigitalZoomcanresultinablurryimageduetotheelectroniczoom.
• Formoredetailsonthrowdistance,seepage120.
[M403H/M323H]
Thefurtheryourprojectorisfromthescreenorwall,thelargertheimage.Theminimumsizetheimagecanbeisap-
proximately30"(0.76m)measureddiagonallywhenprojectorisroughly41inches(1.0m)fromthewallorscreen.The
largesttheimagecanbeis300"(7.62m)whentheprojectorisabout436inches(11.1m)fromthewallorscreen.
300"
Distance
(Unit: m/inch)
Lens center
Screen Size
Screen Size (Unit: cm/inch)
200"
150"
120"
100"
90"
80"
11.1/436"
5.5/216"
4.4/173"
3.6/143"
3.3/129"
2.9/114"
2.2/86"
1.4/56"
40"
7.4/290"
60"
30"
1.0/41"
664(W)�374(H) / 261(W)�147(H)
443(W)�249(H) / 174(W)�98(H)
332(W)�187(H) / 131(W)�74(H)
266(W)�149(H) / 105(W)�59(H)
221(W)�125(H) / 87(W)�49(H)
199(W)�112(H) / 78(W)�44(H)
177(W)�100(H) / 70(W)�39(H)
133(W)�75(H) / 52(W)�29(H)
89(W)�50(H) / 35(W)�20(H)
66(W)�37(H) / 26(W)�15 (H)
