NEC M403W - Adjust the Tilt Foot

19
2. Projecting an Image (Basic Operation)
2
1
3
Adjustable Tilt Foot
Adjustable Tilt
Foot Lever
Adjust the Tilt Foot
1.Liftthefrontedgeoftheprojector.
CAUTION:
DonottrytotouchtheexhaustventduringTiltFootadjustmentas
itcanbecomeheatedwhiletheprojectoristurnedonandafteritis
turnedoff.
2.PushupandholdtheAdjustableTiltFootLeveronthefrontof
theprojectortoextendtheadjustabletiltfoot.
3.Lowerthefrontoftheprojectortothedesiredheight.
4.ReleasetheAdjustableTiltFootLevertolocktheAdjustabletilt
foot.
The tilt foot can be extended up to 2 inches/52 mm.
There is approximately 10 degrees (up) of adjustment for the front of
the projector.
Rotate the rear foot to the desired height in order to square the image
on the projection surface.
CAUTION:
• Donotusethetilt-footforpurposesotherthanoriginallyintended.
 Misusessuchasusingthetiltfoottocarryorhang(fromthewallor
ceiling)theprojectorcancausedamagetotheprojector.
Adjustingtheleftandrighttiltofanimage[Rearfoot]
• Rotatetherearfoot.
The rear foot can be extended up to 1 inch/26.5 mm. Rotating the rear
foot allows the projector to be placed horizontally.
NOTE:
• Donotextendtherearfootbeyonditsheightlimit(0.8inch/21.5mm).Doing
somaycausetherearfoottocomeoutoftheprojector.
• Ifextendingtheleftrearfoot(viewedfromtherear)causestheprotrusionto
interferewiththeoor,extendtherightrearfootby0.5inch/12mmorlonger.
Ifextendingtherightrearfootcausestheprotrusiontointerferewiththeoor,
extendtheleftrearfootby0.3inch/8mm.

Rear feet
Up Down
